Elitewheels Pro33 MTB Wheels

ELITE PRO-33 Wheelset

The Pro33 carbon wheel is designed for cross-country and trail riding. It features a modern rim shape with a 27mm internal width. Paired with the high-precision Elitewheels Pro hubs, it excels even on the most demanding terrain.

Features

The rim

During the rim production process, inflatable internal bladders made of a special material are used to create smoother walls, resulting in a lighter rim. These bladders are then completely removed without the use of harsh chemicals through the valve hole. The unique manufacturing process ensures that the rim does not need to be repaired to remove the bladders, as is the case with traditional manufacturers. This significantly improves the rim's strength.

ELITE uses both genuine Toray T700 and T800 carbon fiber, which is superior to the generic carbon fiber used by many manufacturers. Both types of carbon fiber are used in different locations to increase the wheel's strength-to-weight ratio while reducing lateral and radial forces, and increasing impact resistance.

The rims have also been specifically designed to facilitate the fitting of tubeless tires using a floor pump.

The hubs

The Elitewheels Pro hub is included as standard and is equipped with Taiwanese TPI bearings. The front and rear hubs are made of 7075 aluminum alloy. The lightweight freewheel features a 36-tooth hook system.

The rays

Sapim CX-Ray spokes are standard. ELITE takes special care to minimize spoke twist so the wheels don't become misaligned. After the initial adjustment, the wheel is subjected to a side load. This process is repeated several times. The wheels undergo a total of 16 side loads, which is considered an essential quality control standard. As a result, our wheels are guaranteed to remain within a tolerance of 0.2 mm.

The 3.2mm spoke offset minimizes the difference in spoke tension between the right and left spokes. This creates a stronger and laterally stiffer wheel, giving you better control.

More information on the ELITE PRO 33 website

Technical characteristics

• Wheel diameter: 29" (622 mm)
• Rim dimensions: Width 33 mm, inner 27 mm, height 29 mm.
• Compatible: Inner tube and tubeless
• Number of spokes: 28 front/rear
• Hub dimensions: BOOST 110/15 mm front and 148/12 mm rear
• Standard disc: Centerlock or 6 screws
• UCI certified
• Freewheel Type: Ratchet 36T

Color

• Black

Weight

• 1,359 g ±30 g

Materials

• Rim: Carbon
• Spokes: Sapim CX-Ray
• Hubs : High-strength 7075 T6 aluminum
• Bearings: TPI

Scope of delivery

• Front wheel

• Rear wheel
• Freewheel body
