Monster gravel titanium fork 482 mm BOOST

MTB fork - GRAVEL rigid in TITANIUM 29 inches

CYKL Rigid Titanium MTB GRAVEL Fork, designed for the RAAD-G and RAAD-M . This high-quality fork offers dimensions similar to a suspension MTB fork, with 100/110 mm of travel. Its fork length is 482 mm, with a 45 mm offset. This makes it easy to convert a mountain bike into a gravel bike without changing the geometry of the bike.

The fork is compatible with 1- ½ - 1-⅛ headset and thru axle.

It is offered in two standards

• Boost format 110 × 15 mm.
• Format 100 x 12 mm

It can accommodate tires up to 29 × 2.4 C

Eyelets allow for easy mounting of luggage and accessories.

Two brake cable outlets on the fork tube and on the fork shoulder to make it compatible with all bikes on the market. with internal or external brake cable routing.

This fork is available with two types of cable routing.

• Fully internal The cables come out at the fork tube.
• Semi-internal. The front brake cable exits through the fork shoulder.

Behavior.

We use the same titanium as for our frames, namely Grade 9 Ti3Al-2.5V

Titanium naturally filters vibrations for a more comfortable ride.

This fork allows you to ride comfortably, even on poor-quality surfaces. The exclusive 3D printing process, using technologies from the aerospace industry. Allows for increased stiffness and improved control. You have an increase in lateral and torsional rigidity. The fork does not bend under stress and the control gain is significant. Cornering and braking are more precise. The front wheel benefits from better axial support.

This rigid titanium bicycle fork is virtually indestructible. It has successfully passed the EN 14781 standard test, attesting to its quality and safety. It will not rust or oxidize. It will retain its aesthetic and mechanical properties for many years.

To top it all off, it can be customized with colors and patterns through anodizing, to perfectly match our titanium frames or your bike.

Experience a more comfortable and high-performance ride with the CYKL Titanium Rigid Road Bike Fork.

Technical characteristics

• Area of ​​use: Monster Gravel, cross country mountain biking
• Fork length: (wheel axle to crown): 482 mm
• Rake offset: 45 mm
• Fixing points: six (3 left / 3 right)
• Duct passage : internal and external
• Headset compatible : 1- ½ - 1-⅛
• Thru axle : Standard Boost 110 × 15 mm or Standard non-Boost 100 × 15 mm
• Crown diameter : 55 mm
• Max tire size : 29" × 2.4' C
• Test standard : EN 14781

Color

• Frosted titanium

Weight

• 690 g +- 15 g

Materials

• Titanium Grade 9 Ti3Al-2.5V

Scope of delivery

• 1 x fork with internal cable routing Logo positioning on the fork may change
• 1 x Thru axle
