GRAAVE Frameset titanium fork
The GRAAVE is CYKL's versatile titanium gravel bike, designed for everyday rides, bikepacking, and adventure with stable handling and lasting comfort. Available as a frameset with a 410 mm titanium fork, it provides a robust and ultra-practical full titanium base for demanding builds, even when loaded. All CYKL titanium frames and components come with a lifetime warranty.
Size
Couldn't load pickup availability
CYKL GRAAVE Titanium Gravel Frameset - Titanium Fork
The GRAAVE "Full Titanium" frameset is engineered for metal purists and ultra-distance adventurers. This configuration prioritizes vibration damping and mechanical resilience to deliver absolute comfort on the most demanding terrains, eliminating the fear of carbon failure far from home.
At the core of this platform, the Grade 9 Titanium (Ti3Al-2.5V) frame and matching fork work together to dissipate shock waves. The rear triangle engineering, featuring seatstays connected directly to the top tube, maximizes vertical compliance while maintaining the lateral stiffness needed for heavy loads. It is a reliable, timeless, and repairable exploration tool.
Key Points
- Organic Comfort: The titanium frame and fork combination offers superior natural filtration of high-frequency vibrations compared to carbon.
- Bikepacking Ready: 19 mounting points (eyelets) distributed across the frame and fork for maximum load capacity (cages, fenders, dynamo).
- Durability: A frameset immune to daily knocks and corrosion, ideal for travel without bike boxes or on rough terrain.
- Endurance Geometry: A Stack/Reach ratio engineered to maintain an efficient yet sustainable posture over multiple days in the saddle.
- Generous Clearance: Clearance for tires up to 700x55C to adapt grip and volume to the terrain.
Compatibility
The GRAAVE adheres to modern workshop standards for maximum evolutivity. It is designed around the T47 bottom bracket (68mm) for increased rigidity and easy maintenance. The UDH rear hanger ensures compatibility with all current drivetrains (SRAM Transmission T-Type, Shimano GRX, Mechanical or Di2). Braking is Flat Mount standard (160/140mm).
This frameset is delivered with a 410mm axle-to-crown titanium fork. This is the optimal height to preserve the bike's native geometry. Doubt about your build or component choice? Write to us.
Technical Specs
| Product Name | GRAAVE Frameset (Titanium Fork) |
|---|---|
| Brand | CYKL |
| Frame Weight | 1650g (Size M) - Source CYKL Workshop |
| Fork Weight | Approx. 850g (Uncut steerer) |
| Frame Material | Titanium Grade 9 (Ti3Al-2.5V) |
| Fork Material | Titanium Grade 9 |
| Discipline | Gravel, Bikepacking, Ultra-distance |
| Bottom Bracket | T47 (Internal thread 68mm) |
| Rear Axle | 12x142mm (Thru-Axle) |
| Front Axle | 12x100mm (Thru-Axle) |
| Derailleur Hanger | SRAM UDH (Universal) |
| Headset | Integrated IS52/28.6 - IS52/40 (1.5" full) |
| Seatpost | 27.2mm |
| Tire Clearance | Max 700x55C (depending on rim width) |
| Brake Mount | Flat Mount |
References and Identifiers
| SKU (XS) | FRMST-GRAAVE-FKTI-XS |
|---|---|
| SKU (S) | FRMST-GRAAVE-FKTI-S |
| SKU (M) | FRMST-GRAAVE-FKTI-M |
| SKU (L) | FRMST-GRAAVE-FKTI-L |
| SKU (XL) | FRMST-GRAAVE-FKTI-XL |
| SKU (XXL) | FRMST-GRAAVE-FKTI-XXL |
Geometry
Size guide
| Rider height (cm) | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| Suggested range | <163 | 164–169 | 170–174 | 175–180 | 181–186 | >186 |
Indicative. A bike fit remains the benchmark.
| Mesure (mm) | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| Stack (S) | 536 | 541 | 580 | 604 | 623 | 643 |
| Reach (R) | 382 | 400 | 405 | 408 | 427 | 437 |
| Ratio stack / reach | 1,403 | 1,353 | 1,432 | 1,480 | 1,459 | 1,471 |
| Seat tube length (A) | 462 | 492 | 522 | 552 | 582 | 612 |
| Top tube length (TTL) | 521 | 545 | 555 | 569 | 595 | 611 |
| Effective top tube (EFFTT) | 541 | 562 | 574 | 587 | 612 | 627 |
| Top tube slope (TTS) | 11° | 8° | 9,3° | 8° | 10,2° | 6° |
| Head tube angle (B) | 71° | 71° | 72,5° | 72,5° | 72,5° | 72,5° |
| Seat tube angle (C) | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° | 73,5° |
| Head tube length (D) | 120 | 125 | 145 | 170 | 190 | 210 |
| Chain stay length (E) | 425 | 425 | 432 | 432 | 432 | 432 |
| Front center (FC) | 602 | 623 | 618 | 632 | 657 | 672,2 |
| Wheel base (WB) | 1019 | 1041 | 1039 | 1053 | 1078 | 1093 |
| BB drop (BBD) | 60 | 75 | 75 | 75 | 75 | 75 |
| BB height | 321 | 286 | 286 | 286 | 286 | 286 |
| Fork rake | 50 | 50 | 50 | 50 | 50 | 50 |
| Fork length (FL) | 410 | 410 | 410 | 410 | 410 | 410 |
| Stem length (SL) | 60 | 70 | 70 | 80 | 90 | 90 |
| Handlebar width | 400 | 420 | 420 | 420 | 420 | 440 |
| Crank length | 165 | 165 | 170 | 170 | 175 | 175 |
| Wheel size | 700 | 700 | 700 | 700 | 700 | 700 |
